Loj gantry cnc tshuab rau ntoo
Hlau Tube Welded Ncej
NCSTudio Tswj System
Stpper Tsav Thiab Tsav Tsav
Cua Txias ntxaiv
Lub Tshuab Nqus Tsev (5.5Kw Cua Twj)
Loj gantry cnc tshuab rau ntoo lub ntsiab tseem ceeb
1. Z-Axis Pub Qhov Siab 200MM (qhov siab yuav tau nce)
2. Xwmfab raj welded steel ncej qauv, ruaj khov txaus
3. Nqus T-Qhov Ua Haujlwm Ua Haujlwm
4. X-Axis thiab Y-axis iav Rack Kev Sib Kis, Z-Axis TRI Pob Ntsia Hlau
5. Taiwan txoj kev ua tau zoo linear ntawm x, y, thiab z axes
6. Stepper tsav thiab tsav tsheb (xaiv servo lub cev muaj zog thiab cov tsav tsheb)
7. Cua txias ntxaiv thiab tau ua tiav zaus zaus hloov pauv, ntxaiv kev xaiv
8. NC studio Tswj system, yeem DSP lossis MACH 3
Cov qauv ntawmloj gantry cnc tshuab rau ntoo
Daim Ntawv Thov:
Kev lag luam kho kom zoo nkauj Kho Kom Zoo Nkauj: tuaj yeem carve pob zeb, ntoo, thiab lwm yam, qhov rooj thiab lub qhov rooj, kev tsheb nqaj hlau, murals, thiab lwm yam.
Kev Lag Luam Tshaj Tawm: Siv rau kev ua cov cim, logo, cov laug cam kev lag luam, thiab lwm yam.
Cov khoom siv tes ua haujlwm: Muaj peev xwm carving zoo qauv thiab cov duab ntawm cov ntaub ntawv xws li jade, ntoo, thiab hlau.
Kev Lag Luam Hluav Taws Xob: Carving thiab Npav Yuav Ua Tau Ntawm Cov Khoom xws li Circuit Court thiab Casings
Khoom Parameter
|
Lus piav |
Tsis |
|
Ncho ncho |
loj gantry cnc tshuab rau ntoo |
|
Thaj chaw ua haujlwm |
2000 x 3000 x 200mm |
|
XY COJ |
Khib thiab pinion, iav tsav |
|
Z tawm |
Pob ntsia hlau tsav / Taiwan |
|
Max. hov ceev |
50, 000 hli / min |
|
Max. Txiav Ceev |
25, 000 hli / min |
|
Ntxaiv Hwjchim |
3.5kW cua txias ntxaiv |
|
Tsav Motors Tsav Tsheb |
Stepper tsav |
|
Kev Ua Haujlwm Voltage |
AC220V / 380V, 50-60 hz, 3- theem |
|
Hais Txog Code |
G code |
|
Khoos phis tawj Interface |
USB 2. 0 |
|
Lub rooj |
Nqus Tsev |
|
tus maub los |
NCSTudio Tswj System |
|
ntim loj |
3600 * 2250 * 1850mm |
| Qho hnyav | 1800kg |
Cov ntsiab lus tseem ceeb rau kev yuav ntawm lub tshuab:
Xaiv cov cuab yeej xaiv raws li kev ua haujlwm, CNC system, lub cev muaj zog thiab tsav lub kaw lus, thiab lwm yam
Nthuav dav ntawm loj gantry cnc tshuab rau ntoo
tshuab dhos txaj
Lub tshuab pam saws thickened loj square raj welded txaj welded txaj, uas tsis muaj deformation, reliage kev ua tau zoo, ruaj khov
Cua Txias ntxaiv
Huab cua txias spindle tuaj yeem sai sai dissipate kub, txhim kho kev ua haujlwm tau zoo, thiab ua rau nws yooj yim dua.
Nqus Tsev
Nws tuaj yeem unsorb unsorb, tsis hais lawv tus qauv lossis loj npaum li cas, thiab tuaj yeem ruaj khov kom tsis txhob txav chaw thiab tshee hnyo thaum carving, kom paub tseeb
Ntawv hmoov av
X-axis nrog cov ntaub ntawv pov thawj plua plav los tiv thaiv lub tshuab los ntawm cov hmoov av paug qias tuaj
Siab Loos
Lub log siab tuaj yeem pab cov khoom siv kom zoo dua
stepper tsav
Stepper motors muaj qhov tseeb thiab muaj zog txhawb nqa
Folinn Inverter
Lub luag haujlwm tseem ceeb ntawm kev hloov pauv zaus yog tswj qhov nrawm ntawm lub cev muaj zog ntxaiv.
Cov tsav tsheb
Tuam Tshoj tus neeg tsav tsheb zoo uas muaj kev ruaj khov tau ruaj khov thiab ceev tsis siv neeg txias txias.
Tsis Siv Neeg Lim Dej
Txiav, sij hawm, thiab noobtitively muab cov roj nplua zog mus rau lubrication ntsiab lus ntawm cov khoom siv kho tshuab
Txwv Hloov
Omron hluav taws xob txwv hloov, kev ntseeg tau zoo thiab teb sai
Tuam txhab ntaub ntawv
Muaj 15 xyoos ntawm kev paub kev lag luam
Cov khoom lag luam zoo zoo, nrog cov khoom lag luam ntsuas xws li CE thiab SGS
Hoobkas ncaj qha muag ntawm tus nqi qis
Peb muaj cov kws tshaj lij thiab cov neeg muag khoom cov neeg ua haujlwm uas tuaj yeem muab kev cob qhia thiab tom qab kev pab cuam
