Mini CNC Router 6060 Rau Jade Acrylic Ntoo PVC MDF Hlau Txiav Thiab Carving
chaw ua haujlwm 600 * 600 * 100mm
Cam khwb cia hlau txaj
Pob ntsia hlau kis tau tus mob
Hiwin rail rau peb axis
DSP A11 tswj qhov system
Leadshine tsav tsheb M542
Stpper lub cev muaj zog
1.5KW dej txias ntxaiv
Cov6060 Desktop Movement CNC Routermuaj ntau yam qauv: HT-3030, HT-4040, HT-6090, thiab nws tsuas yog siv rau engraving txhuas, tooj liab thiab lwm yam mos hlau thiab ntoo, acrylic, mdf thiab lwm yam ntaub ntawv nonmetal.
Kev ua haujlwm parameter
|
tus lej |
Kev piav qhia |
Parameter |
|
1 |
XYZ chaw ua haujlwm |
600 * 600 * 100 hli |
|
2 |
Rooj loj |
640 * 640 hli |
|
3 |
XYZ ncig xyuas qhov tseeb |
± 0.01 hli |
|
4 |
XYZ repositioning positioning raug |
± 0.01 hli |
|
5 |
Gantry |
cam khwb cia-aluminium |
|
6 |
tshuab dhos qauv |
hlau casting |
|
7 |
Tsav system X-Y axis |
Pob ntsia hlau |
|
8 |
Tsav system Z axis |
Pob ntsia hlau |
|
9 |
Spindle zog |
1.5 KW TSI |
|
10 |
Max ceev |
8m / min |
|
11 |
Max ua hauj lwm ceev |
6m / min |
|
12 |
Spindle ceev |
0-24000rmp |
|
13 |
Hom haujlwm |
Stepper |
|
14 |
Ua haujlwm voltage |
AC 220 V |
|
15 |
Lus txib |
G kod |
|
16 |
Interface |
USB los yog parallel chaw nres nkoj |
|
17 |
Kev khiav haujlwm |
Ncstudio/DSP/Mach3 |
|
18 |
Flash nco |
128 |
|
19 |
X-Y daws teeb meem |
0.025 hli |
|
20 |
Software ib puag ncig |
Wentai type3 artcam |
|
21 |
Kev khiav ib puag ncig |
Kub: 0-45 ° C |
Xaiv tau accessories
1. 6060 Desktop Movement CNC Routersiv stepper lub cev muaj zog lossis servo lub cev muaj zog, rau cov neeg siv khoom uas xav tau kev ua haujlwm siab. Servo motors muaj kev ua haujlwm siab dua thiab nrawm dua li stepper motors, tab sis tus nqi kuj tseem siab.
2. 6060 Desktop Movement CNC Routertuaj yeem hloov 2.2KW lossis 3.2KW dej-txias ntxaiv, siab- lub zog ntxaiv muaj zog thiab tuaj yeem txiav cov ntaub ntawv tuab
3. Lub rotating axis tuaj yeem muab ntxiv rau cov ntaub ntawv kos nrog cov duab tshwj xeeb, thiab cov nyhuv 3D engraving kuj zoo dua.
Tshuab qhov tseem ceeb
dsp tswj qhov system
Dsp A11 tswj qhov system yooj yim siv thiab tsuas yog 16 Keys, txhawb USB chaw nres nkoj.
dej txias spindle
Lub tshuab siv 1.5kw dej txias ntxaiv, ceev ceev thiab suab nrov tsawg
Inverter thiab tsav tsheb
Zoo tshaj los yog Fuling inverter, leadshine tsav tsheb thiab lwm yam
tshuab lache txaj
Cam khwb cia hlau lub cev, peb -axis pob ntsia hlau kis hom.
Lwm qhov chaw
Tshuab qauv
me hlau cnc router tuaj yeem ua cov plywood, cork, hardwood, nruab nrab ntom fiberboard, particleboard, Acrylic, ABS, HDPE, PVC, UHMW, HDPE, txhuas, tooj dag, tooj liab thiab lwm yam.
Procession of Production
Ua tshuab dhos txaj
Sib dhos lub tshuab
Tshawb xyuas lub tshuab
Kuaj lub tshuab
Ntoo crate packing tshuab
Tshuab kev thauj mus los
Jinan HOPETOOL CNC Equipment Co., Ltd. yog lub tuam txhab kev tshaj lij uas tsim, tsim, thiab muag CNC router tshuab, laser tshuab, thiab cov tshuab txiav digital. Tom qab 15 xyoo ntawm kev ua haujlwm nyuaj, peb cov tshuab tau raug xa tawm mus rau ntau dua 80 lub teb chaws thiab peb tau tsim kev sib raug zoo ua lag luam nrog ntau tus neeg xa khoom los ntawm ntau lub teb chaws.
Peb lub tuam txhab tau tsim nyob rau hauv 2011 thiab muab siab - zoo CNC engraving tshuab, laser tshuab, flatbed txiav machine thiab lwm yam CNC khoom rau ntau tshaj 80 lub teb chaws thoob ntiaj teb.
Peb qhov chaw nyob
Qihe Industrial Park, Dezhou City, Shandong xeev
FAQ
Q1: Kuv tsis paub dab tsi txog CNC router engraving tshuab, yuav ua li cas xaiv lub tshuab zoo rau kuv txoj haujlwm?
A1: Yuav tsum tau qhia kuv cov khoom koj xav ua, qhov siab tshaj plaws thickness koj xav tau txiav, qhov siab tshaj plaws (ntev thiab dav). Tom qab ntawd kuv yuav pom zoo lub tshuab tsim nyog tshaj plaws rau koj.
Q2: Thaum kuv tau txais lub tshuab, tab sis kuv tsis paub yuav siv nws li cas, kuv yuav ua li cas?
A2: Lub tshuab los nrog cov ncauj lus kom ntxaws txog kev teeb tsa thiab ua haujlwm phau ntawv thiab video, thiab tib lub sijhawm ua ntej koj tau txais lub tshuab no, peb cov kws ua haujlwm pabcuam yuav hu rau koj ua ntej, koj tuaj yeem tiv tauj lawv txhua lub sijhawm.
Q3: Yog tias muaj teeb meem nrog CNC router engraving tshuab, kuv yuav ua li cas?
A3: 1) Hu rau peb, peb cov engineers nyob online 24 teev hauv ib hnub, npaj ua haujlwm rau koj txhua lub sijhawm.
2) Yog tias cov khoom seem puas lawm hauv peb lub sijhawm lav, peb yuav muab cov khoom dawb rau koj.
Yog tias cov khoom seem raug puas sab nraum lub sijhawm lav, peb yuav muab rau lawv ntawm tus nqi.
Q4: Thaum kuv tau txais lub tshuab no, kuv puas yuav tsum tau npaj lwm qhov los ua kom lub tshuab no ua haujlwm?
A4: Rau lub tshuab no, peb tau muab tag nrho cov khoom ua haujlwm, koj tsis tas yuav npaj, tsuas yog nruab.
Q5: Dab tsi yog hom shipping thiab lub sij hawm ntau lawm?
A5: Peb muab EXW, FOB, CIF, DDU thiab DDP, koj tuaj yeem xaiv raws li koj xav tau.
Tom qab koj them cov nyiaj tso cia, peb yuav npaj cov khoom thiab nws yuav xa tuaj hauv 7-15 hnub. Txog 30 hnub rau cov tshuab customized.
